Kyocera FS-1020D Installation Guide

Caution
NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION.
Notice on Software
SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION
MODE. The printer is factory-set to emulate the HP PCL 6. The emulation mode can be changed by
following the procedures described in the Operation Guide contained as an electronic file in the
Kyocera Mita Document Library CD-ROM supplied with the printer.
Notice
The information in this manual is subject to change without notification. Additional pages may be
inserted in future editions. The user is asked to excuse any technical inaccuracies or typographical
errors in the present edition.
No responsibility is assumed if accidents occur while the user is following the instructions in this
manual. No responsibility is assumed for defects in the printer's firmware (contents of its read-only
memory).
This manual, any copyrightable subject matter sold or provided with or in connection with the sale
of the page printer, are protected by copyright. All rights are reserved. Copying or other reproduc-
tion of all or part of this manual, any copyrightable subject matter without the prior written consent
of Kyocera Corporation is prohibited. Any copies made of all or part of this manual, any
copyrightable subject must contain the same copyright notice as the material from which the copy-
ing is done.
Table of Contents
STEP 1 Unpacking .......................................................................1
STEP 2 Positioning the Printer....................................................3
STEP 3 Installing the Toner Container........................................4
STEP 4 Connecting the Printer to the Computer .......................7
STEP 5 Connecting the Power Cord...........................................9
STEP 6 Adding Paper to the Paper Cassette and MP Tray......10
STEP 7 Printing a Status Page..................................................17
©2003 by KYOCERA MITA CORPORATION All rights reserved. Revision 1.0., September 2003
Ifs1020ep-eng.book 1 ページ ２００３年９月３日 水曜日 午後４時４７分

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
