Troubleshooting
OPERATION GUIDE 10-7
2
Open the Scan Unit.
3
Open the Front Cover.
4
Lift the Developer Unit together with the
Toner Container out of the printer.
5
Using the green handles lift the Drum Unit
out of the machine.
NOTE: The Drum Unit is sensitive to light.
Never expose the Drum Unit to light for
more than five minutes.
6
If the jammed paper appears to be pinched
by rollers, pull it along the normal running
direction of the paper.
To Next Page
