8-4 Option
Installing the Memory Module
1
Turn off the printer and disconnect the power cord and printer cable.
2 Remove the right cover.
3 Remove the screw and open the inner cover.
4 Remove the memory module from its package.
5 Aligning the cutouts of the memory module with the matching keys of
the socket, carefully plug the memory module into the memory
socket until it clicks in place. Then, push down the memory module
to secure.
6 After you finish installing the memory module, secure the inner cover
with screws removed in step 3, and close the right cover.
Removing a Memory Module
To remove a memory module, remove the right cover and the memory
slot cover from the printer. Then, carefully push out the two socket
clamps. Ease the memory module out of the socket to remove.
Verifying the expanded memory
To verify that the memory module is working properly, test it by printing a
status page.
