4-2 Connecting and Printing
Connections
This section explains how to start up the printer. The figure shown below is
the overviews of connections between the printer and the computer.
Connecting the USB Cable
Follow the steps as below for connecting the USB cable.
1 Connect the USB cable (not included) to the USB interface
connector at the rear of this machine.
2 Connect the other end of the USB cable to the computer's USB
interface connector.
Connecting the Network Cable
Follow the steps as below for connecting the network cable.
1 Remove the cap and connect the shielded network cable (not
included) to the computer and the hub (concentrator).
2 Connect the other side of the network cable to the network interface
connector at the rear of this machine and the hub.
Connecting the Parallel Cable
Follow the steps as below for connecting the parallel cable.
1 Connect the parallel cable to the parallel interface connector at the
rear of this machine.
2 Connect the other side of the parallel cable to the computer’s
interface connector at the rear of this machine.
Note Use a USB cable with a rectangular Type A plug and a
square Type B plug. The USB cable should be shielded and
no longer than 5 meters (16 feet) long.
Note Use a parallel printer cable that complies with IEEE 1284
standards. For optimum performance, install the printer close to
the PC. The connection cable should be shielded and no longer
than 3 meters (10 feet) long. The cable is solid separately
.

Table of Contents

Other manuals for Kyocera FS-2020D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-2020D and is the answer not in the manual?

Kyocera FS-2020D Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Memory typeDDR2
Processor modelPowerPC 440
Maximum internal memory1152 MB
Sound power level (standby)29 dB
Sound pressure level (printing)52 dB
Power supply type220/240 V, 50/60 Hz
Capacity cartridge12000 sheets
Power consumption (active)560 W
Recommended monthly print volume20000 pages
Maximum duty cycle150.000 pages per month
Number of print cartridges1
Total input capacity500 sheets
Total output capacity250 sheets
Maximum input capacity1100 sheets
Maximum number of input trays2
Multi-Purpose tray input capacity100 sheets
Maximum print size216 x 356 mm
Paper tray media typesPlain paper, Recycled paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)9.2 W
Power consumption (PowerSave)5.7 W
Energy Star Typical Electricity Consumption (TEC)2.6 kWh/week
DisplayLCD
CertificationGS, TüV, CE
Standard interfacesParallel, USB 2.0
Optional connectivityEthernet, Wireless LAN
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)382 x 394 x 285 mm
