4-22. Security > Encryption > Exporting Certificate
The certificate can be downloaded to Windows Vista / 7 for printing via IPP over SSL.
4-23. Security > IPSec > General
Contact information can be registered for support. This is a convenient setting for entering contact information of the dealer or service
center, for example.
E-mail Address Enter the e-mail address. Whitespace is allowed.
Issue Date Displays the date that the certificate was issued.
Expiration Date Specifies the expiration date of the certificate.
Item Description
Certificate Click Export to download the certificate.
Item Description
IPSec Enable (on) or disable (off) the IPSec.
Restriction
Specify the default policy for packets other than IPSec protocol.
Authentication Type
Select the encryption scheme that will be used for IKE phase1 from the following choices.
— Pre-Shard
— Certificate
Pre-shared Key
Enter the string of the pre-shared key.
Expiration Verification Enable (on) or disable (off) the verification of certificate expiration.
Root Certificate Upload the root certificate by clicking Browse button.
CA-issued Device Certificate Upload the CA-issued device certificate by clicking Browse button.
Password Enter the password for the CA-issued device certificate.
Mode Select the key exchange mode from the following choices.
— Main Mode
— Aggressive Mode
Hash Select the hash algorithm from the following choices.
— MD5
— SHA-1
Encryption Select the encryption algorithm from the following choices.
— 3DES
— AES
Diffie-Hellman Group Select the Diffie-Hellman group to use from the following choices.
— modp768(1)
— modp-1024(2)
— modp-1536(5)
— modp-2048(14)
— modp-4096(16)
— modp-6144(17)
Page 1
of 2
Using a Web Browser to Manage the I
-51
10
2
201
