Kyocera FS-2100DN Management Guide

4-3. Protocols > TCP/IP > IP Filters (IPv6)
IP Filters(IPv6) can be used to specify the host or network that can use IB-51. Up to 10 access list entries can be specified.
4-4. Protocols > TCP/IP > Logical Printers
The IB-51 can be used as a virtual printer that adds or replaces strings (commands) at the start or end of job data. You can configure
up to eight logical printers.
Logical printers use FTP, LPR, or IPP as the communication protocol. Printouts to nonexistent ports are all sent to Logical Printer 1.
Subnet Mask
Specify the subnet mask to allow access from. To allow access from all hosts over the network
192, enter "192.0.0.0" for IP address and "255.0.0.0" for subnet mask. It is possible to leave this
field blank.
Protocols Select the protocols that will be allowed to access from the following choices.
— LPD
— FTP
— IPP
— HTTP
— RAW Port
— SNMP
— HTTPS(IPPS)
— ThinPrint
Item Description
IP Address (IPv6)
Specify the IP address to allow access from.
Prefix Length
Specify the prefix length for IPv6 (0-128 decimal characters).
Protocols Select the protocols that will be allowed to access from the following choices.
— LPD
— FTP
— IPP
— HTTP
— RAW Port
— SNMP
— HTTPS(IPPS)
Item Description
TCP/IP Port Number You can designate the port number for logical printers just as you can designate the physical port
number for TCP (such as 9100). Data sent to the designated physical port is converted in a way
corresponding to the designated logical printer. If you designate the same port number as a port
that was previously designated (such as for FTP or LPD), the port designation is invalid.
Bi-directional Printing You can enable (On) or disable (OFF) bi-directional printing that uses the physical port for TCP/IP
communication. If this setting is off, all data received from the printer is disregarded. When printing
with PostScript, PJL, or other commands, bi-directional printing must be on to return data to the
client that was received from the printer.
Start of Job String You can designate a string to be sent to the printer before direct output to the output port (lp port).
If you need to send a control code before printing, designate that string.
End of Job String You can designate a string to be sent to the printer after direct output to the output port (lp port). If
you need to send a control code after printing, designate that string.
Banner Page Banner page printing can be enabled (On) or disabled (Off) when printing via FTP or LPD.
Filter Setting Select ASCII to KPDL to enable the filter setting.
Page 9 of 2
2
Using a Web Browser to Manage the I
B
-51
10
/
2
/
201
2
file:///C:/Tom/PDF/I
B
-51/I
B
-51%20Setu
p
%20Guide%20HTML%20En
g
lish/card
_
home
pa
...
