Kyocera FS-6030MFP

LE 03 ConstructionLE 03 Construction
Pa
p
er feed unit
The registration roller has a big diameter to prevent paper
curl.
p
Paper loop
Cassette
Regist
& feed
Feed from the cassette’s
The Paper feed drive is started approximately 25ms prior to the secondary feed for registration of the
leading edge of the paper.
Paper
loop
Cassette
feed
Regist
&
feed
roller feed
NAME
Cassette feed clutch
Regist sensor
Regist clutch
