Kyocera FS-6030MFP

LE 03 ConstructionLE 03 Construction
Dit
The main parts of the drum unit are:
• a-Si drum
• Charge roller
• Cleanin
g
blade and cleanin
g
roller
D
rum un
it
gg
• LED-bracket to erase
• Sweep roller for waste toner
• DK Relay PWB
The drum surface
p
otential is 270V
(
+/-20V
)
p(
)
The waste toner bottle is controlled by a LED
(WTL) - Sensor (WTS) combination.
The life time of the drum is specified to
300.000 pages.
1. Drum
2. Charger roller
3. Charger cleaning roller
4. Charger case
5. Cleanin
g
blade
g
6. Cleaning roller
7. Scraper
8. Sweep roller
9. Drum frame
10. Cleaning lamp (CL)
