Kyocera FS-6970DN Operation Guide

Troubleshooting 5-7
KPDL error ##
Press GO
Current print processing cannot continue because of occurrence of KPDL error which is
categorized by ##. To print out an error report, display >>Error Report from the menu
system, and select On. Press [GO] to resume printing. You can abandon printing by pressing
[Cancel].
If Auto Error Clear is set to On, printing will be automatically resumed after a preset period of
time.
Load Cassette #
(A4) / (PLAIN)
The paper cassette matching the paper size and paper type of the print job is empty. Load
paper into the paper cassette as displayed in place of #. Printing resumes automatically.
If you want to print from a different paper source, press U or V to select the alternative paper
source, and then press [OK].
When you press [MENU], Paper Settings > appears. Press U or V to select the paper
size and type of the paper source. Press [OK] to display Use alternative? and then
press [OK]. Printing starts using the specified the paper source.
Load MP Tray
(A4) / (PLAIN)
There is no paper cassette installed in the printer that matches the paper size and paper type
of the print job. Set paper in the MP tray. Printing resumes automatically. (Note that feeding
the paper having a paper size which does not match the current paper size from the MP tray
can cause paper jam.)
If you want to print from a different paper source, press U or V to select the alternative paper
source, and then press [OK].
When you press [MENU], Paper Settings > appears. Press U or V to select the paper
size and type of the paper source. Press [OK] to display Use alternative? and then
press [OK]. Printing starts using the specified the paper source.
Low security
This message is displayed when Low was selected in Security Level.
Memory overflow
Press GO
The total amount of data received by the printer exceeds the printer’s internal memory.
Try adding more memory. Press [GO] to resume printing. You can abandon printing by
pressing [Cancel].
If Auto Error Clear is set to On, printing will be automatically resumed after a preset period of
time.
MemoryCard err##
Press GO
A CompactFlash card error has occurred. Look at the error code given in place of ## and
refer to CompactFlash (CF) Card and USB Flash Memory Errors on page 5-9. To ignore the
CompactFlash card error, press [GO].
MemoryCard err20
The CompactFlash card is accidentally inserted and removed from the printer’s slot during
the printer is on. Turn the power switch off, insert the CompactFlash card, and then turn on
the printer again.
Missing
developer unit
The developer unit is either not installed or incorrectly inserted. Insert the developer unit
securely.
No multi copies
Press GO
Multiple copies cannot be printed because the RAM disk is disabled or the hard disk is not
installed. There is no available RAM disk or hard disk space. Delete unnecessary files. Press
[GO] to print error report.
Original toner
installed
Displayed when the installed toner is the original Kyocera product.
Paper jam
###############
A paper jam has occurred. The location of the paper jam is indicated in place of the #’s. For
details, refer to Clearing Paper Jams on page 5-11.
Paper path error
When one or more optional feeders are installed, this message will appear if any of the paper
feeders or the printer cassette upper than the selected one is not properly closed.
Message Corrective Action

Kyocera FS-6970DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor model	440
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Power requirements	AC 220-240 V, 50/60 Hz
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	1350 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	802.1x RADIUS, SSL/TLS
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.6 W
Power consumption (printing)	516 W
Power consumption (PowerSave)	6.3 W
Certification	GS, TÜV, CE
Product color	Black, Grey
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Standard interfaces	Ethernet, Parallel, USB 2.0
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	469 x 395 x 285 mm
