1. Preparations
1-1 Accessories
• 1 CD-ROM
• This Instruction Handbook
1-2 Required items
• Parallel cable
1-3 Name of parts (main body)
1 Parallel interface connector
Connect a bi-directional parallel cable here.
2 Memory Card (CompactFlash) slot
Insert the optional Memory Card (CompactFlash) here.
3 Main switch
Turn this switch ON ( | ) first, prior to using the printer. Always
turn this switch OFF (O) when connecting the printer cable,
etc.
4 Operation panel
Use when performing settings, etc., at the printer itself.
<This illustration above shows the 15 ppm copier complete with the Optional drawer.>
