Kyocera KM-C2525E Service Manual

2JL/2JJ/2JG/2JD
1-5-9
8. Remove two screws and remove the scan-
ner left cover.
Figure 1-5-19
9. Remove two screws and remove the scan-
ner right cover.
Figure 1-5-20
10. Remove the contact glass.
Figure 1-5-21
Scanner left cover
Scanner right cover
Contact glass
