Installing and Setting up the Machine > Using the Operation Panel
Using the Operation Panel
Operation Panel Keys
1[Home] ( ) key: Displays the Home screen.
2[Job Separator] ( ) indicator: Lights when there is paper in the job separator tray.
3[Data] ( ) indicator: Blinks while the machine is printing or sending/receiving, or accessing the hard disk/SSD. Also,
it lights when there is a sending job FAX using delayed transmission.
4[Attention] ( ) indicator: Lights or blinks when an error occurs and a job is stopped.
5[Energy Saver] ( ) key: Puts the machine into Sleep Mode. Recovers from Sleep if in Sleep Mode.
6 Touch Panel: Displays icons for configuring machine settings.
Adjusting the Operation Panel Angle
The angle of the operation panel can be adjusted.
1 2 3 4 5
6
