4. Instrument layout
4-1 Instrument layout
１LCDdisplay
２RangeSwitch
３Testbutton
４BackLightbutton
５DISPbutton
６LineTerminal
７EarthTerminal
８GuardTerminal
９LineProbe(red)
10EarthCord(black)
11GuardCord(green)
12 Protectivefigerguard
Itisapartprovidingprotectionagainstelectricalshockand
ensuringtheminimumrequiredairandcreepagedistances.
１
２３
４
５
６
７
８
９1011
12 12
12
