8-2 How to use the adaptor for recorder
MODEL8302 is an adaptor for a recorder (option) for output
currentmeasurement.Connectitasshowninthebelowfigure.
OutputisDC1mVwhencurrentof1μAisflowing.
+
－
To recorderTo shield
or Earth
