5. Getting started
5-1 Checking the battery voltage
(1)SettheRangeswitchtoanypositionotherthanOFF.
(2)WhentheBatterymarkshownattheupperleftontheLCD
islastonelevel
,thebatteriesarealmostexhausted.
Replace the batteries with new ones to perform further
measurements.
Theinstrumentoperatesproperlyevenifundersuchalow
batterylevel,anditmaynotaffectontheaccuracy.
When the empty Battery mark
 appears, the battery
voltageisbelowthelowerlimitoftheoperatingvoltage.So
theaccuracycannotbeguaranteed.
Please refer to clause 7. Battery Replacement, for the
batteryreplacementprocedures.
5-2 Connecting test leads
Insert the test lead firmly to the connector terminal on the
instrument. Connect the Line Probe(red) to the Line terminal,
the Earth Cord(black) to the Earth terminal and the Guard
Cord(green) to the Guard terminal. A Guard cord connection
maynotberequired,ifthereisnoneedtoestablishaguard.
#DANGER
●If the Test button ispressedwhentheRangeswitchisat
theinsulationmeasurementpositions,highvoltagemaybe
appliedtothetestleadsandyoumaygetanelectricshock.
●Stopusingthetestleadiftheouterjacketisdamagedand
theinnermetalorcolorjacketisexposed.
