KYORITSU KEW3125A - Measurement - Backlight and Auto-Power-Off; Backlight Function Usage; Auto-Power-Off Function


24

*Itispossibletomoveoutthesurfaceleakageresistanceof
the insulation and measure only the volume resistance by
using the Guard terminal. This is helpful when performing
testsinhumidair.
6-7 Backlight function
Thisfunctiontofacilitateworkingatdimlyilluminatedlocation
oratnighttimework.
Press the backlight button when the range switch is at any
position other thanOFF. The backlight will light up for
about 60sec, and then turn offautomatically.(The lightwill
notturnoffautomaticallyduringameasurement.)
6-8 Auto-power-off function
The instrument will automatically turn itselfoff if there is no
function change or button press for about 10min. To return
to the normal mode, turn the Range switch to OFF position
once, and then to any desired position. (This function does
not work during a measurement or while the instrument is
givinganaudibleandvisiblelivecircuitwarning.)
