48 PD3000 Quick Start Guide 49
NuQ118B
NuQ102
4-pole cable
2-pole cable
PD3000
Mode switch: Mono
Channel A Xover switch: Full Range
Channel B Xover switch: LF
M32R
Mode Back Panel Connector Internal Schematic
Passive
HPF
HF
NL4
Input/
Link
1+
1 -
2+
2 -
>
>
>
>
>
>
>
>
1+
1 -
2+
2 -
NL4
Input/
Link
LPF
LF
speakON NL4
1-
2-
2+
1+
PASSIVE, Input Full Range -
PASSIVE, Input Full Range +
2+/2-
speakON NL4
Passive, Input Full Range +
Passive, Input Full Range -
Input Sub +
Input Sub -
Amplier Channel 2
Passive Output +
Passive Output -
1-
2-
2+
1+
2-Wire Link to Passive Full Range
NL4
Input/
Link
1+
1 -
2+
2 -
>
>
>
>
>
>
>
>
1+
1 -
2+
2 -
NL4
Input/
Link
LF
Amplier Channel 1
1-
2-
2+
1+
M32R
4. Applications
Bi-amping splits a signal into upper and lower frequency bands, and then assigns each frequency band to separate speaker cabinets. A subwoofer typically takes the
low frequency range. By splitting the signal this way, the speakers work more eciently, and you can achieve a cleaner overall sound.
One side sub and linked passive top, Turbosound NuQ102 and NuQ118B together with Lab.gruppen PD3000
