Lab.gruppen PDX3000 User Manual

38 PDX3000 Quick Start Guide 39
TFM122M
M32R
4-pole cable
Mode Back PanelConnector Internal Schematic
Bi-Amp
HF
NL4
Input/
Link
1+
1 -
2+
2 -
>
>
>
>
>
>
>
>
1+
1 -
2+
2 -
NL4
Input/
Link
LF
speakON NL4
BI-AMP, Input Low +
BI-AMP, Input Low -
BI-AMP, Input High +
BI-AMP, Input High -
1-
2-
2+
1+
Amplier Channel 1
Amplier Channel 2
Pre-set: TFM112M_BI AMP
PDX3000
Fullrange monitor in bi-amp mode, Turbosound TFM122M together with Lab.gruppen PDX3000
