46 PDX3000 Quick Start Guide 47
Other important information
1. Register online. Please register your new
Music Tribe equipment right after you purchase it by
visiting labgruppen.com. Registering your purchase using
our simple online form helps us to process your repair
claims more quickly and e ciently. Also, read the terms
and conditions of
our warranty, if applicable.
2. Malfunction. Should your Music Tribe
Authorized Reseller not be located in your vicinity,
you may contact the Music Tribe Authorized Ful ller for
your country listed under “Support” at labgruppen.com.
Should your country not be listed, please check if your
problem can be dealt with by our “Online Support” which
may also be found under “Support” at labgruppen.com.
Alternatively, please submit an online warranty claim at
labgruppen.com BEFORE returning the product.
3. Power Connections. Before plugging the
unit into a power
socket, please make sure you are using
the correct mains voltage for your particular model.
Faulty fuses must be replaced with fuses of the same type
and rating without exception.
Important information
8. Specifications
General
Number of ampli er channels 2
Number of processing channels 2
Peak total output all channels driven 3000 W
Peak output voltage per channel 115 V
Peak output current per channel 32 A
Bridge mode No
Output circuit type Class-D
Ampli er Outputs
Max Output Power
All channels driven
2 Ω per channel 1000 W
4 Ω per channel 1500 W
8 Ω per channel 800 W
Audio Performance
THD+N 20 Hz - 20 kHz @ 1 W < 0.1%
THD+N @ 1kHz, 1 dB below clip < 0.1%
Signal-to-noise >90 dB
Channel separation (Crosstalk)
@ 1 kHz
>75 dB
Frequency response 10 Hz to 20 kHz, +0.5/ -1 dB
Input impedance 10 kΩ unbalanced,
20 kΩ balanced
Internal Sample rate 96 kHz
Product propagation delay 0.6 ms
Distortion,1/8 rated power < 0.1%
System
Controls
Front Power switch
Gain controls (channels A and B)
DSP section rotary push-encoder
Buttons for Process, Setup,
Up/Down, Exit
Remote Via USB for PDX Controller software
running on computer
Indicators
Display LCD 128 x 32, White text on black
background
Power RDY LEDs lit green
Limit, per channel LIM LEDs lit red
Signal, per channel -24 dB, -12 dB, -6 dB LEDs lit green
Thermal Warning, per channel RDY LED blink orange
Thermal Warning 90%, PSU Both RDY LEDs blink orange
Thermal fault, per channel RDY LED blink red
Thermal fault
100%, PSU Both RDY LEDs blink red
Fault, channel RDY LED lit constantly red
Fault, device Both RDY LEDs constantly lit red
System
Integrated DSP features
Delay 0 – 300 ms
Crossover function 3 lter types, up to 48 dB/oct.
EQ function 8-band parametric, 2-band
dynamic equalizer
Limiter Zero attack limiter (peak)
Presets 20 total presets, 19 user-de nable
Connectors
Inputs / link 2 x XLR
2 x ¼ " TRS
Outputs Neutrik speakON (2 x NLT4)
USB connector Rear pane
l USB connector type B for
remote control of DSP section with
PDX Controller Software
Mains connector Locking IEC appliance inlet, C14
Protection Features
Cooling Two fans front-to-rear air ow,
temperature controller speed
Ampli er protection Thermal and DC protection, Rail
sensing and peak current limiting.
Load protection Controlled
start and shutdown
behavior, DC-fault protection,
Short-circuit protection
Power Supply
Voltage Separate 230 V and 115 V versions
available. Not selectable on the
product.
USA / Canada / Japan 100-120 V, 50/60 Hz
UK / Australia / Europé / Korea / China 220-240 V, 50/60 Hz
Power consumption @ 4 ohms,
rated power
1050 W
Dimensions / Weight
Dimensions (H x W x D) 93 x 483 x 326 mm (3.7 x 19 x 12.8")
Weight 6.5 kg (14.3 lbs)
Finish Black painted aluminium chassis and
grey front
ApprovalsCE, UL (ANSI/UL, CAN/CSA), PSE, RCM,
CCC, FCC
To Next Page
