35
Product Service 1-800-522-7658
Chapter 7: Modifying Your Protector Fume Hoo
Figure 7-3 Knob Figure 7-4 Valve
Installing Guardian™ Digital
Airflow Monitor or Guardian™ Jr.
Airflow Monitor
The Guardian Digital Airflow Monitor P/N 9743201 or Guardian
Jr. Airflow Monitor P/N 9743202 allows you to continuously
monitor face velocity through the fume hood opening. The fume
hood right corner post is factory prepared to mount either monitor.
Contact Labconco Customer Service to order.
Figure 7-6 Figure 7-7
Distillation Grids – Field
Installation
The distillation grid P/N’s 9725200 thru 9725206, have been
strategically placed with the vertical rod center lines in front of the
lower baffle and middle baffle. The distillation grids allow the
hood user to mount glassware, motors, stirrers, and other
apparatus. Contact Labconco Customer Service for ordering
information.
Figure 7-5 Hose Connector
