Chapter 1: Introduction
Appendix C: Protector XStream Hood Specifications contains the
electrical requirements for laboratory fume hood. Wiring diagrams
are also included.
Appendix D: References lists the various resources available that
deal with laboratory fume hoods.
Typographical Conventions
Recognizing the following typographical conventions will help
you understand and use this manual:
• Book, chapter, and section titles are shown in italic type (e.g.,
Chapter 3: Getting Started).
• Steps required to perform a task are presented in a numbered
format.
• Comments located in the margins provide suggestions,
reminders, and references.
• Critical information is presented in boldface type in paragraphs
that are preceded by the exclamation icon. Failure to comply
with the information following an exclamation icon may result
in injury to the user or permanent damage to fume hood.
• Critical information is presented in boldface type in paragraphs
that are preceded by the wrench icon. These operations should
only be performed by a trained certifier or contractor. Failure
to comply with the information following a wrench icon may
result in injury to the user or permanent damage to your hood.
• Important information is presented in capitalized type in
paragraphs that are preceded by the pointer icon. It is
imperative that the information contained in these paragraphs
be thoroughly read and understood by the user.
• A number icon precedes information that is specific to a
particular model of laboratory fume hood. The 4' icon
indicates the text is specific to the 4-foot wide model. The 5'
icon indicates the text is specific to the 5-foot model, etc.
• The S icon indicates the text is specific to the standard model.
• The A icon indicates the text is specific to the A-Style
Combination Sash Model.
☞
4'
5' 6'
!
S
A
