42
Product Service 1-800-522-765
ppendix A: Protector Component
Item Quantity Part No. Description
4J 1 9819000 Nut, Hose Barb - NOT SHOWN
5 1 9825500 Label, Knob (contains all the labels)
6 1 9818900 Lens, Knob
7A 1 9826600, 01, 02 115V Duplex Receptacle (GRAY) Right, Left 4' - 6', Left 8' w/ wires
7B 1 9818200 Cover Plate 115V Duplex
7C 1 9826603, 04, 05 115V GFCI Duplex Receptacle (GRAY) Right, 4' - 6', Left 8' w/ wires
7D 1 9818100 Cover Plate, 115V GFCI
7E 1 9818300 Cover Plate, Blank
8A 1 9721901 Lamp, Fluorescent (T8 x 3') – use on 4' & 8' Hoods-NOT SHOWN
8B 1 9721900 Lamp, Fluorescent (T8 x 4') – use on 5' & 6' Hoods-NOT SHOWN
9 1 9826900 Ballast Assy (used on T8 Slimline) – NOT SHOWN
10A 1 1302300 Switch, Rocker
10B 1 1327500 Switch, Plug (Fills cutout when switch is not used)
11A 1 9818400 Access Cover
11B 1 9825100 Label, Access Cover (includes all three corner labels)
12A 1 9810801 Side Panel, 30" internal deep hoods (NOT SHOWN)
12B 4 1916400 Nut, Retainer #10-24
12C 4 1885512 Screw, Machine #10-24 x .75 Truss Head Stainless
13A 1 9813800 Air Foil 4'
13B 1 9813801 Air Foil 5'
13C 1 9813802 Air Foil 6'
13D 1 9813803 Air Foil 8'
14 4 1861400 Pulley, Front or Rear, 1-3/16 Dia.
15 2 4949902 Cable, Sash 130" – NOT SHOWN
16 2 1663200 Bumper, Rubber – (upper sash bumper)
17 4 1920100 Clamp, Cable Replacement – NOT SHOWN
18 2 1972100 S-Hook – NOT SHOWN (to attach weight to cable)
19A 1 9826300 Wiring Harness, Main
19B 1 9826400 Wiring Harness, Ballast 115V, 4' - 6'
19C 1 9826700 Wiring Harness, Ballast 115V, 8'
20 1 9807600, 01, 02,
03
Front Panel, 4', 5', 6', 8'
21 1 9724501 Sash Stop Kit (XStream)
22 1 1886908 Screw, #10-32 x .50 Phillips Stainless
23 1 1598500 Hinged Screw Cap Cover
