Illustration A-1 indicate the location of the following service parts:
Item Quantity Part No. Description
1A 1 9817000 Valve, Labconco ¼" Compression Fitting
1B 1 9817001 Valve, Labconco 3/8" Compression Fitting
1C 1 9817002 Valve, Labconco Deionized ¼" Compression Fitting
1D 1 9817003 Valve, Labconco Deionized 3/8" Compression Fitting
1E 1 9818000 Nut, Valve Mtg. (Labconco)
2A 1 9826800 WaterSaver Valve/Gooseneck -GRN
2B 1 9826801 WaterSaver Valve/Connector (VAC) – YEL
2C 1 9826802 WaterSaver Valve/Connector (AIR) – ORG
2D 1 9826803 WaterSaver Valve/Connector (GAS) – BLU
2E 1 9826805 WaterSaver Valve/Connector (HOT WATER) – RED
2F 1 9826806 WaterSaver Valve/Connector (CW) – GRN
2G 1 9826807 WaterSaver Valve/Connector (STEAM) – BLK
2H 1 9826808 WaterSaver Valve/Connector (NITROGEN) – BRN
2I 1 9826809 WaterSaver Valve/Connector (OXYGEN) – LIGHT GREEN
2J 1 9826810 Swivel Gooseneck only – GRN
2K 1 9826812 Swivel Gooseneck only – WHITE
3 1 9818700
thru 08
Knobs (GRAY, GRN, BLU, ORG, YEL, RED, WHT, BLK,
BRN)
4A 1 9818800 Hose Barb, GRAY – (NEUTRAL OR ARGON)-NOT SHOWN
4B 1 9818801 Hose Barb, GREEN - (COLD WATER)-NOT SHOWN
4C 1 9818802 Hose Barb, BLUE – (GAS)-NOT SHOWN
4D 1 9818803 Hose Barb, ORANGE – (AIR)-NOT SHOWN
4E 1 9818804 Hose Barb, YELLOW – (VACUUM)-NOT SHOWN
4F 1 9818805 Hose Barb, RED – (HOT WATER)-NOT SHOWN
4G 1 9818806 Hose Barb, WHITE – (DEIONIZED WATER) NOT SHOWN
4H 1 9818807 Hose Barb, BLACK–(NEUTRAL OR STEAM) NOT SHOWN
4I 1 9818808 Hose Barb, BROWN – (NITROGEN) NOT SHOWN
Protector XStream Replacement Parts
