Chapter 3: Getting Started
Product Service 1-800-522-7658
9
Original instructions
Telescoping Base Stands
These stands are included with some Logic+ models, or are available
separately. The base stands for each width cabinet are listed in Table 3-1
below. An optional caster wheel kit is available (part # 3730500).
Width Base Stand w/Feet Model #
3' 3401003
4' 3401004
5' 3401005
6' 3401006
Manual or Electric Hydraulic Lift Base Stands
These base stands offer infinitely adjustable height between 25.5 and 33.5
inches (648 to 851 mm), giving a cabinet work surface height of 28.0 to 36.0
inches. The height is adjusted either by a manual (hand crank) or electric
pump that drives hydraulic rams in the legs of the stands. All of the hydraulic
stands are equipped with fixed feet, but can be converted to caster wheels
with the addition of Caster Kit #3784000. The base stands for each cabinet
size is listed in Table 3-2 below.
Width Manual Lift Stand # Electric (115V) Lift Stand # Electric (230V) Lift Stand #
3' 3780200 3780100 3780103
4' 3780201 3780101 3780104
5' 3780203 3780106 3780107
6' 3780202 3780102 3780105
Note: When installing the cabinet on the hydraulic lift base stand, ensure that
the hydraulic lines and the electrical cord are clear of any obstructions before
installing the cabinet on the stand or operating the lift system.
SoLo
TM
Electric Hydraulic Lift Base Stands
These base stands permit the Logic+ to be lowered enough to be transferred
through a standard doorway as low as 78 inches. Casters provide mobility
and lock in place. The SoLo Stands for each Purifier Logic+ series model is
listed below.
115V SoLo Stand #
230V SoLo
No. America
Plug #
230V SoLo
UK Plug #
230V SoLo
Schuko Plug #
230V SoLo
China/Australia
Plug #
3' 3780310 3780314 3780330 3780334 3780338
4' 3780311 3780315 3780331 3780335 3780339
5' 3780312 3780316 3780332 3780336 3780340
6' 3780313 3780317 3780333 3780337 3780341
Table 3-1
Table 3-2
