Labconco Purifier Logic+ 30231 Series - Appendix C: Specifications; Electrical and Motor Specifications

Product Service 1-800-522-7658
51
Original instructions
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
C
C
:
:
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Electrical Data
Model # Requirements
3023xxx0x 115 VAC, 60 Hz, 12 Amps
3023xxx1x 100 VAC, 50/60 Hz, 12 Amps
3023xxx-20, 30, 40, 50, 60, 70 230 VAC, 50/60 Hz, 6 Amps
3024xxx0x 115 VAC, 60 Hz, 12 Amps
3024xxx1x 100 VAC, 50/60 Hz, 12 Amps
3024xxx-20, 30, 40, 50, 60, 70, 80 230 VAC, 50/60 Hz, 6 Amps
3025xxx0x 115 VAC, 60 Hz, 16 Amps
3025xxx1x 100 VAC, 50/60 Hz, 16 Amps
3025xxx-20, 30, 40, 50, 60, 70 230 VAC, 50/60 Hz, 8 Amps
3026xxx0x 115 VAC, 60 Hz, 16 Amps
3026xxx1x 100 VAC, 50/60 Hz, 16 Amps
3026xxx-20, 30, 40, 50, 60, 70 230 VAC, 50/60 Hz, 8 Amps
Motor Specifications
Cabinet Model Electrical Requirements
All 3- and 4-foot
Cabinets, all Voltages
1/2 H.P. Electronically Commutated Motor (ECM)
120-277 VAC – 50/60 Hz,
Full Torque – 42 Oz.-Ft (3.56 N-M)
7.7 Full Load Amps @115VAC
4.3 Full Load Amps @230VAC
Automatic Thermal Protection
Cabinet Model Electrical Requirements
All 5- and 6-foot
Cabinets, all Voltages
3/4 H.P. Electronically Commutated Motor
120-277 VAC – 50/60 Hz,
Full Torque – 66 Oz.-Ft (5.59 N-M)
9.6 Full Load Amps @115VAC
6.8 Full Load Amps @230VAC
Automatic Thermal Protection
