Labconco Purifier Logic+ 30231 Series User Manual

Product Service 1-800-522-7658
54
Original instructions
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
E
E
:
:
Q
Q
u
u
i
i
c
c
k
k
C
C
h
h
a
a
r
r
t
t
Model 30231_ 30238_ 30241_ 30248_
30248xx80
30251_ 30258_ 30261_ 30268_
Type A2 A2 A2 A2 A2 A2 A2 A2 A2
Cabinet Size (in feet) 3 3 4 4 4 5 5 6 6
Sash Opening (inches) 10 8 10 8 8 10 8 10 8
Starting Serial #
1
1303_ 1303_ 1303_ 1303_ 1312_ 1303_ 1303_ 1303_ 1303_
Nominal Avg. Downflow (FPM) 55+/-5 55+/-5 55+/-5 55+/-5 70+/-5 55+/-5 55+/-5 55+/-5 55+/-5
Nominal Average Inflow (FPM) 105+/-5 105+/-5 105+/-5 105+/-5 105+/-5 105+/-5 105+/-5 105+/-5 105+/-5
Supply HEPA Data
Labconco P/N 3838400 3838400 3838401 3838401 3838401 3838402 3838402 3838403 3838403
Exhaust HEPA Data
Labconco P/N 3838500 3838500 3838501 3838501 3838501 3838502 3838502 3838503 3838503
Motor/Blower Data
Labconco P/N
2
3832200 3832200 3832201 3832201 3832201 3832207 3832207 3832208 3832208
Motor HP 1/2 1/2 1/2 1/2 1/2 3/4 3/4 3/4 3/4
Fluorescent/UV Lamp Data
Fluorescent Lamps (2 each) F25T8
TL741
F25T8
TL741
F32T8
TL741
F32T8
TL741
F32T8
TL741
F40T8
SP41
F40T8
SP41
F40T8
SP41
F40T8
SP41
UV Lamp G30T8 G30T8 G30T8 G30T8 G30T8 G30T8 G30T8 G30T8 G30T8
1. The primary serial tag is on the lower outside edge of the right corner post.
The secondary serial tag is located on the front of the electronics module on
the top right side of the cabinet. The first two digits of the serial number are
the year of production; the next two are the month. The next 5 digits are the
sequence of production, and the letter following the serial number is the
revision level of the cabinet.
2. Each motor must be programmed by Labconco for the appropriate width
cabinet.
