60 | HPI Combi Flow User Guide | Version 3.11 www.lafert.com

10.3.5. Object Dictionary

Binary Value Object:

Binary Value Objects Table

Instance ID Object Name Access Description Active/Inactive Text

BV0 Run/Stop State R This object indicates drive run status RUN/STOP

BV1 Trip State R This object indicates if drive is tripped TRIP/OK

BV2 Hand Mode R This object indicates if drive is in hand or auto mode HAND/AUTO

BV3 Inhibit Mode R This object indicates drive is hardware inhibit INHIBIT/OK

BV4 Mains Loss R This object indicates if mains loss happened YES/NO

BV5 Fire Mode R This object indicates drive is in ﬁre mode ON/OFF

BV6 Enable State R This object indicates if drive has enable signal YES/NO

BV7 External 24V Mode R This object indicates drive is in external 24V mode YES/NO

BV8 Maintenance Due R This object indicates if maintenance service is due YES/NO

BV9 Clean Mode R This object indicates if pump clean function is on ON/OFF

BV10 Terminal Mode R This object indicates if drive is in terminal control mode ON/OFF

B V 11 Bypass Mode R This object indicate if drive is in bypass mode ON/OFF

B V 12 Digital Input 1 R Status of digital input 1 ON/OFF

B V 13 Digital Input 2 R Status of digital input 2 ON/OFF

BV 14 Digital Input 3 R Status of digital input 3 ON/OFF

B V 15 Digital Input 4 R Status of digital input 4 ON/OFF

BV16 Digital Input 5 R Status of digital input 5 ON/OFF

BV 17 Digital Input 6 R Status of digital input 6 ON/OFF

BV 18 Digital Input 7 R Status of digital input 7 ON/OFF

B V 19 Digital Input 8 R Status of digital input 8 ON/OFF

BV20 Relay Output 1 R Status of relay output 1 CLOSED/OPEN

BV 21 Relay Output 2 R Status of relay output 2 CLOSED/OPEN

BV22 Relay Output 3 R Status of relay output 3 CLOSED/OPEN

BV23 Relay Output 4 R Status of relay output 4 CLOSED/OPEN

BV24 Relay Output 5 R Status of relay output 5 CLOSED/OPEN

BV25 Run/Stop CMD C Drive run command object RUN/STOP

BV26 Fast Stop C Fast stop enable object ON/OFF

BV27 Trip Reset C Trip reset object (rising edge active) ON/OFF

BV28 Coast Stop C Cost stop enable object (overrides fast stop) ON/OFF

BV29* Relay 1 CMD C User speciﬁed relay output 1 status CLOSED/OPEN

BV30* Relay 2 CMD C User speciﬁed relay output 2 status CLOSED/OPEN

BV31* Relay 3 CMD C User speciﬁed relay output 3 status CLOSED/OPEN

BV32* Relay 4 CMD C User speciﬁed relay output 4 status CLOSED/OPEN

BV33* Relay 5 CMD C User speciﬁed relay output 5 status CLOSED/OPEN

* This function only works if the relay output can be controlled by user value (Refer to the HP Combi Flow Parameter List for further

details)

Serial Communications
