Analog Value Object
Analog Value Objects Table
Instance ID Object Name Access Description Units
AV0 Motor Frequency R Motor output frequency Hertz
AV1 Motor Speed R Motor output speed (0 if P1-10=0) Rpm
AV2 Motor Current R Motor output current Amps
AV3 Motor Power R Motor output power Kilowatts
AV4 Motor torque R Reserved %
AV5 DC Bus Voltage R DC bus voltage Volts
AV6 Drive temperature R Drive temperature value °C
AV7 Drive Status R Drive status word NONE
AV8 Trip Code R Drive trip code NONE
AV9 Analog input 1 R Value of analog input 1 Percent
AV10 Analog input 2 R Value of analog input 2 Percent
A V 11 Analog output 1 R Value of analog output 1 Percent
A V 12 Analog output 2 R Value of analog output 2 Percent
AV 13 PID Reference R PID controller reference value Percent
AV 14 PID feedback R PID controller feedback value Percent
AV 15 Speed Reference C Speed reference value object Hertz
AV16 User Ramp Time W User ramp value Seconds
AV17 User PID Reference W PID controller user reference Percent
AV18 User PID Feedback W PID controller user feedback Percent
AV 19 Kilowatt Hours R Kilowatt hours (can be reset by user) Kilowatt-hours
AV20 Megawatt Hours R Megawatt hours (can be reset by user) Megawatt-hours
AV 21 KWh meter R Kilowatt hours meter (cannot be reset) Kilowatt-hours
AV22 MWh meter R Megawatt hours meter (cannot be reset) Megawatt-hours
AV23 Total Run Hours R Total run hours since date of manufacture Hours
AV24 Current Run Hours R Run hours since last time enable Hours
10.3.6. Access type
R - Read only
W - Read or Write
C - Commandable
10.3.7. Supported Service
  WHO-IS (Reply with I-AM, and I-AM will also be broadcasted on power up and reset)
  WHO-HAS (Reply with I-HAVE)
  Read Property
  Write Property
  Device Communication Control
  Reinitialize Device
10
Serial Communications
