57
4 CMS Components
NOTICE
The limits of the technical data must be strictly adhered to.
Part number
SDO Safe Digital Output component Type 668R0500-XX
*
* XX = depends on configuration
Function
Supply voltage
Module
Outputs
24 VDC (by connecting plugs from MCC)
230 V/120 V +10/-15 %, 47-63 Hz, 24 VDC ± 20 %
Backup fuse max. for outputs 8 A quick-acting
Current draw Min: 40 mA
Max: 170 mA
Power consumption 5 W
Digital outputs I
max
= 2 A per output
cos   0.2
Max. total current over all outputs: 8 A
Housing
Dimensions (H × W × D) [mm] 120 × 45.3 × 121
Weight [kg] 0,335
Flammability UL94 V-0
Environmental conditions
Operation Climatic conditions Class 3K5 according to DIN EN 60721-3-3, 5-95%
Mechanical conditions Class 3M5 according to DIN EN 60721-3-3
Temperature range î›30 … +70°C (non-condensing)
Transportation Climatic conditions Class 2K4 according to DIN EN 60721-3-2, ï‚£ 95%
Mechanical conditions Class 2M2 according to DIN EN 60721-3-2
Temperature range î›40 … +80°C (non-condensing)
Storage Climatic conditions Class 1K3 according to DIN EN 60721-3-1, 5-95%
Mechanical conditions Class 1M2 according to DIN EN 60721-3-1
Temperature range î›40 … +80°C (non-condensing)
Electrical safety IP rating according to DIN EN 60529 IP20 (as long as all terminals are mounted)
