Lamtec GUI607

69
4 CMS Components
4.7 UI400 - User Interface
4.7.1 For Your Safety
See chapter 2 Safety
4.7.2 Technical Data
Fig. 4-35 UI400 photo
Fig. 4-36 UI400 mounting dimensions
Cut-out for UI400 installation: 108 mm × 61 mm:
Part number
UI400 user interface, connection via LSB Type 668R0300
Function
Supply voltage Via LSB
Power consumption 1 W
