lancer 4500 Series - Recommended Plumbing, Eight (8) Valve; Recommended Plumbing, Six (6) Valve

 *'%%&($-%!&! ,.$.
FOR ASSISTANCE CALL 1-800-729-1500
RECOMMENDED PLUMBING
SODA/WATER #5
SODA/WATER #3,4
SODA/WATER #1,2,6
06-1181/02
3-2-1 CONFIGURATION
SYRUP LINES NOT SHOWN
SYRUP #2 SYRUP #1 SYRUP #4 SYRUP #3 SYRUP #6 SYRUP #5
6 5 4 3 2 1
SODA/WATER #1,2,3 SODA/WATER #6,7,8
SODA/WATER #4
SODA/WATER #5
SYRUP #2 SYRUP #3 SYRUP #4 SYRUP #5 SYRUP #6
8 7 6 3 2 1
RECOMMENDED PLUMBING
SYRUP LINES NOT SHOWN
3-1-1-3 CONFIGURATION
FOR ASSISTANCE CALL 1-800-729-1500
PART NO: 06-2226
5 4
SYRUP #1 SYRUP #7 SYRUP #8
