lancer IBD 30 - Illustrations and Part Listings; Post-Mix Dispenser Assemblies

24
Final Assembly, Post-Mix, IBD
ILLUSTRATIONS AND PART LISTINGS
Part No. Description
85-4526H IBD22H, Series 4500, 115V/60Hz,6 Valve
85-4548H IBD30H, Series 4500, 115V/60Hz,8 Valve
85-4536H IBD22H, Series 4500, 230V/50-60Hz,6 Valve
85-4558H IBD30H, Series 4500, 230V/50-60Hz,8 Valve
10
1
9
11
12
13
15
14
8
9
NOTE:
TO ADJUST ICE FLOW
REGULATOR, SEE SECTION 1.5
(230 VOLT ONLY)
7
6
3
4
2
5
1
