lancer Sensation - Page 20

20
TROUBLE CAUSE REMEDY
Circuit breaker tripping 1. Valve wire harness shorted to itself or
faucet plate
2. Controller PCB is bad
3. Secondary wire harness has a short
4. Power supply is bad
1. Detect short by disconnecting valve
harnesses from switch panel (4 25-pin
harnesses and 4 9-pin harnesses).
Restore power. If breaker does not trip,
nd and replace shorted harness. If
breaker trips, re-install the 8 harnesses,
and proceed to next step.
2. Detect by disconnecting the white 5-pin
harness from the controller PCB. Restore
power. If breaker does not trip, replace
controller PCB. If breaker trips, re-install
the white 5-in harness and proceed to next
step
3. Locate short from a motor or solenoid
harness and replace.
4. Detect short by disconnecting all
harnesses connected to power supply.
Restore power. If breaker still trips, replace
power supply
BIB pump does not operate
when dispensing valve is
opened
1. Out of CO
2
, CO
2
not turned on, or low CO
2
pressure
2. Out of syrup
3. BIB connector not tight
4. Kinks in syrup or gas lines
1. Replace CO
2
supply, turn on CO
2
supply,
or adjust CO
2
pressure to 70-80 PSI (0.482
- 0.552 MPA)
2. Replace syrup supply
3. Fasten connector tightly
4. Straighten or replace lines
BIB pump operating, but no
ow
1. Leak in syrup inlet or outlet line
2. Defective BIB pump
1. Replace line
2. Replace BIB pump
BIB pump continues to
operate when bag is empty
1. Leak in suction line
2. Leaking o-ring on pump inlet tting
3. Defective syrup BIB pump
1. Replace line
2. Replace o-ring
3. Replace defective pump
BIB pump fails to restart after
bag replacement
1. Leak in discharge line or ttings
2. Empty BIB
3. Air leak on inlet line or bag connector
1. Tighten BIB connector
2. Clean out or replace BIB connector
3. Straighten or replace line
BIB pump fails to stop when
dispensing valve is closed
1. Leak in discharge line or ttings
2. Empty BIB
3. Air leak on inlet line or bag connector
1. Repair or replace discharge line
2. Replace BIB
3. Repair or replace
Low of no carbonation 1. Low or no CO
2
2. Low water pressure
3. Worn or defective carbonator pump
4. Backow preventer not allowing water to
ow
5. Probe malfunctioning
6. PCB malfunctioning
1. Check CO
2
supply. Adjust CO
2
pressure to
70 PSI (0.482 MPA).
2. Need water booster kit
3. Replace carbonator pump
4. Replace backow preventer, noting the
ow direction arrow from pump to coldplate
5. Replace probe
6. Replace PCB
