TOUCHPOINT SPECIFICATIONS
DIMENSIONS
Width: 10 3/8 in (264 mm)
Depth: 25 1/4 in (641 mm)
Height (w/out legs): 22 15/16 in
(583 mm)
SPACE REQUIRED
Left Side: 4 in (101.6 mm)
Right side: 4 in (101.6 mm)
Back: 4 in (101.6 mm)
Top: 8 in (203.2 mm)
ELECTRICAL
115VAC/60Hz/4.3AMPs
230-240VAC/50-60Hz/2.6AMPs
WEIGHT
Empty: 89 lbs (40.4 kg)
Operating: 125 lbs (55.4 kg)
Shipping: 108 lbs (49.0 kg)
ICE
Capacity: 16 lbs (17.26 kg)
FITTINGS
Water for carbonator inlet:
3/8” barb
Plain water inlet: 3/8” barb
Brand syrup inlets: 3/8” barb
Injection avor inlets: 1/4” barb
CO2 inlet: 3/8” barb
CARBONATOR WATER SUPPLY
Min owing pressure: 35 PSIG
(0.241 BAR)
Max static pressure: 60 PSIG
(0.414 BAR)
CARBON DIOXIDE (CO2)
Min pressure: 70 PSIG
(0.483 BAR)
Max pressure: 80 PSIG
(0.552 BAR)
4
