LANDA PGDC • 8.916-596.0 • REV. 5/13
OPERATOR’S MANUAL
PRESSURE WASHER
20
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.706-604.0 Tank, Fuel, 5 Gal., Red
1.110-050.0, 1.110-051.0 1
2 8.706-603.0 Tank, Fuel, 10 Gal. Poly Yellow 1
3 8.921-148.0 Strap, Fuel Tank Single
1.110-049.0 2
1.110-050.0, 1.110-051.0 1
4 9.802-193.0 Gasket, Neoprene 7"
1.110-049.0 2
1.110-050.0, 1.110-051.0 3
5 9.802-053.0 Bushing,
Rubber, Nitrile
1.110-049.0
2
1.110-050.0, 1.110-051.0 3
6 9.802-054.0 Elbow, Fuel Tank, Zinc 1
7 8.706-496.0 Diptube Assy, Plastic, 17.5"
1.110-049.0 1
1.110-050.0, 1.110-051.0 2
8 8.912-192.0 Top Wrap, Stainless Steel 1
9 9.802-071.0 Trim, 750 B2 x 1/16 Black 33"
10 9.800-002.0 Label, Use Only Kerosene 1
11 9.800-006.0 Label, Warning, Hot/Caliente
w/Arrows 1
12 6.390-126.0 Hose Clamp
1.110-049.0 7
1.110-050.0, 1.110-051.0 9
13 8.706-727.0 Bushing, 5/16", Snap Lok 1
14 8.918-426.0 Hose, 3/8" x 32", 2 Wire
Pressure LO 1
15 8.918-425.0 Hose, 3/8" x 29", 2 Wire,
Pressure LO 1
16 9.802-781.0 Nut, 3/8" Whiz 6
17 8.718-980.0 Washer, 5/16" Flat, SAE 23
18 9.802-776.0 Nut, 5/16" ESNA, NC 23
19 9.802-261.0 Hose, 3/4" 39"
20 9.802-728.0 Threaded Bolt 3/8" x 2" 2
21 9.802-779.0 Nut, 3/8" 2
22 9.802-807.0 Washer, Flat, 3/8" 2
23 9.802-259.0 Hose, 1/2" Push-on 24"
24 9.802-151.0 Swivel, 1/2" JIC FEM Push-on 2
25 8.707-020.0 1/2" MPT x 3/4" Barb 1
26 8.900-839.0 Label, PGDC Skid Warning 1
27 9.802-152.0 Swivel,
3/4" SAE Fem, Push-on
1
28 9.802-767.0 Screw,
3
/8" x 3/4" HH,
NC, Whiz
13
29 8.718-674.0 Bolt, 3/8-16 x 2-1/4", GR8.2
Serated Flange B 2
30 8.752-918.0 Clamp, Hose #64SS 1
31 9.802-781.0 Nut, 3/8" Flange Whiz Loc NC 2
32 8.706-600.0 Battery, M-100, Large 1
ITEM PART NO. DESCRIPTION QTY
33 8.916-471.0 Assy, Power Platform
PGDC5-3500 1
34 8.932-992.0 Mount, Rubber Vibration. 3/8"
70 Duro 9
35 8.920-485.0 Wlmt, Skid, PGDC 1
36 9.802-089.0 Cap, Tank
1.110-049.0 1
1.110-050.0, 1.110-051.0 2
37 9.800-001.0 Label, This Tank for Gas Only 1
38 8.920-295.0 Support, Coil, Skid 1
39 8.707-000.0 Connector, 1/2" Anchor 1
40 9.802-781.0 ▲ Nut, 3/8 Flange Whiz 8
41 9.802-797.0 Screw,
#10 x 1/2" Hex Head SS
1
42 9.802-064.0 Grommet, Rubber Nozzle
Holder 4
43 8.932-960.0 Label, Diesel, Black on Yellow 1
44 8.916-274.0 Label, Gas, White on Red 1
45 8.920-352.0 Retainer, Fuel Line 4
46 8.900-266.0 Label, Nozzle 1
47 9.802-753.0 Screw, 1/4" x 3/4" 2
48 9.800-975.0 Label, Landa Logo 4.75 x 21" 1
49 9.803-277.0 Screw, 5/16 x 1/2 Whiz Loc 4
50 8.916-443.0 Wlmt, Back Electrical, PGDC 1
51 9.802-514.0 Strain Relief, LT., Str., 1/2 NPT
.23-45D 2
52 9.802-525.0 Locknut, 1/2" 8463 2
53 8.916-619.0 Panel, PGDC 1
54 9.802-428.0 Cord, Service SJOWA 12/3 30"
55 9.802-765.0 Screw, 1/4" x 1/2" 4
56 8.932-968.0 Label, Intended For Outdoor,
Use, USA 1
57 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF 1
58 9.800-040.0 Label, Ground Symbol 1
59 9.802-695.0 Nut, 10/32" Keps 4
60 9.802-762.0 Screw, 10/32" x 1-1/4"
RH, SL, Blk 1
61 9.802-802.0 Washer, 1/4", FLAT, SAE 4
62 8.718-781.0 Screw, 40mm, Pan HD 1
63 9.800-034.0 Label, Clear Lexan, 4.3" x 5.5" 1
64 8.751-215.0 Grommet, Remote Vent 1
65 8.709-089.0 Clamp, "Wire/Tube .6250" 1
66 8.706-735.0 Bushing, 1-1/4" Snap 1
67 8.712-353.0 Nozzle, SAQCMEG 0005, Red 1
68 8.712-354.0 Nozzle,
SAQCMEG 1505Yellow
1
69 8.712-355.0 Nozzle,
SAQCMEG 2505 Green
1
70 8.712-356.0 Nozzle,
SAQCMEG 4005 White
1
71 8.706-744.0 Plug, Plastic, 1" 1
To Next Page
