POWER PLATFORM EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 Engine, See Specification Page
2 9.802-695.0 Nut, 10/32" Keps 1.110-049.0 1
3 Pump, See Specification Page
4 8.916-442.0 Wlmt, Platform PGDC 1
5 9.802-764.0 Screw, 10/32 x 3/4 Hex, Wash
SL Mach/Blk 1.110-049.0
6 Pump Pulley, See Spec. Page
7 Engine Pulley, See Spec. Page
8 8.709-089.0 Clip, .25ID Rnd 1.110-049.0 1
9 Pump Bushing, See Spec. Page
10 Engine Bushing, See Spec. Page
11 9.802-125.0 Plug, 1/4" JIC 1.110-049.0 1
12 9.802-153.0 Swivel, 1/4" JIC Fem, Push-on
1.110-049.0 1
13 9.803-845.0 Bolt, 1/2" x 5" NC HH Tap
All Thread 1
14 9.802-800.0 Washer, 1/2" Flat 1
15 9.802-767.0
Screw, 3/8" x 3/4" HH,
NC Whiz
11
16 9.802-154.0 Plug, Push-on, Oil Drain,
Honda 1.110-049.0 1
17 9.802-779.0 Nut, 3/8" 2
18 9.802-807.0 Washer, Flat 3/8" 8
19 9.802-959.0 Key, 0.247 Sqr x 2.125" 1
20 8.912-457.0 Assy. Gas Belt Guard, Left, MS
SLT, SLX 1.110-050.0,
1.110-051.0 1
8.916-484.0 Wlmt, Belt Guard, 1.110-049.0 1
21 9.802-254.0 Hose, 1/4" 1.110-049.0 7"
22 8.916-610.0 Guard, Belt, Left 1
23 9.800-006.0 Label, Warning, Hot/Caliente
w/Arrows 2
24 8.932-965.0 Label, Warning,
Exposed Pulleys 2
25 9.802-775.0 Nut, 1/4" Flange, ZN
1.110-050.0 3
26 8.913-902.0 Key, Ring Landa 1
27 9.802-445.0 Wrap, Spiral 8"
28 8.716-491.0 Cable, Battery, 61"
Eye to Post, Red 1
29 8.716-492.0 Cable, Battery, 61" Eye to Post
Black 1
30 9.802-761.0 Screw, M6 x 20mm BH SOC
Black 1.110-051.0 4
31 9.802-259.0 Hose, 1/2" Push-on 7
32 9.802-151.0 Swivel, 1/2" JIC Fem, Push-on 1
33 9.802-126.0 Plug, 1/2" JIC Flare 639F-8" 1
34 9.802-728.0 Threaded Bolt 3/8" x 2" 2
35 9.802-771.0 Screw, 10/32" X 3/4"
BH SOC CS 2
ITEM PART NO. DESCRIPTION QTY
36 9.802-695.0 Nut, 10/32" Keps 2
37 8.750-737.0 Adapter, Honda ,
M20-1.5 x 3/8" 1
38 8.707-019.0 Push-on, 1/2" Barb x 3/8" MPT 1
39 8.750-497.0 Muffler, Honda, Right 1
40 8.739-597.0 Bolt, Flange, 8 x 20mm,
GX610/620 2
41 8.725-319.0 Nut, 7.16-14 Nyl, INS LN ZC 2
42 8.725-320.0 Bolt, 7/16-14 x 2 Hex Tap
GRD5 ZC 2
43 9.802-809.0 Washer, 1/2" Flat, SAE 4
44 9.803-008.0 Shield, Heat, Muffler Guard 1
45 8.715-697.0 Belt, BX36 2
46 8.707-019.0 Push-on 1/2" Barb x 3/8" MPT
1.110-050.0 1
47 9.802-259.0 Hose, 1/2" Push-on
1.110-050.0 7"
48 9.802-151.0 Swivel, 1/2" JIC Fem, Push-on
1.110-050.0 1
49 9.802-126.0 Plug, 1/2" JIC Flare, 639F-8"
1.110-050.0 1
50 9.802-716.0 Bolt, 5/16" x 2" NC HH
1.110-050.0 4
51 9.802-776.0 Nut, 5/16" ESNA, NC
1.110-050.0 4
52 8.718-980.0 Washer, 5/16" Flat SAE
1.110-050.0 4
53 9.802-672.0 Muffler, Exhaust, Briggs,
1.110-050.0 1
54 9.802-867.0 Guard, Muffler, 16 HP Vanguard
1.110-050.0 1
55 9.802-868.0 Brace, Vanguard, Muffler Bracket
1.110-050.0 2
56 9.802-830.0 Screw, Hex 1/4"-20 x 1/2"
T/F TCS 1.110-050.0 4
57 9.802-754.0 Screw, 1/4" x 1/2" HH, NC,
Whiz Loc 1.110-050.0 5
58 9.802-794.0 Nut, Cage, 1/4" x 12 Ga
1.110-050.0 2
59 9.803-011.0 Shield, Heat, Vanguard
1.110-050.0 1
60 8.716-011.0 Conduit, Flexo 48"
62 8.753-065.0 #10 Clamp (Honda) 2
63 8.711-785.0 Hose, 3/8" Push-on 6"
64 8.753-270.0 Reducer, connector 3/8" x 1/4" 1
65 8.753-065.0 #7 Clamp
Honda 1
Vanguard 2
66 8.753-269.0
Reducer, Connector 1/4" x 3/16"
1
To Next Page
