Landa Pgdc4-3500 - LT.1 Series Pump Parts List

LANDA PGDC • 8.916-596.0 • REV. 5/13
35
PRESSURE WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
39* 9.803-187.0 O-Ring Ø1.78 x10.82 3
40* 9.803-154.0 Teflon Ring 3
41*
See Kit Below Plunger 3
42*
See Kit Below Copper Spacer 3
43 9.803-143.0 Plunger Rod 3
44 9.803-157.0 Connecting Rod 3
45 9.802-912.0 Snap Ring 6
46 9.802-915.0 Connecting Rod Pin 3
47 9.802-889.0 Spring Washer 6
48 9.802-937.0 Connecting Rod Screw 6
49 9.803-194.0 O-Ring Ø2.62 x 152.07 1
50 9.803-166.0 Crankcase Cover 1
51 9.803-197.0 Gasket, G3/8 1
52 9.803-202.0 Sight Glass G3/4 1
53 9.802-939.0 Cover Screw 5
* Part available in kit (See below)
REPAIR KIT NUMBER
8.916-488.0 8.916-322.0 9.802-607.0 9.802-603.0 9.802-606.0
KIT
DESCRIPTION
Plunger
"U" Seal
20mm,
LT-6035.1
LT-4035.1
"U" Seal
Packing Assy
20mm
LT-6035.1
LT-4035.1
Plunger
20mm
LT-6035.1
LT-4035.1
Complete Valve
(all pumps)
Plunger Oil Seals
(all pumps)
ITEM NO.’S
INCLUDED
4, 7, 22 4, 5, 6, 7, 8, 9,10 37, 38, 39, 40, 41, 42 12, 13, 14 3
NUMBER OF CYLINDERS
KIT WILL SERVICE
3 1 1 6 3
LT.1 SERIES PUMP PARTS LIST (CONT)
