J8 : Main board ARM Programming Selection
0(2-3) : Enable
1(1-2) : Disable (default)
J9/J10: PHY I2C Source Selection
(2-3) : From Tool
(1-2) : From CPU (default)
PIN
DESCRIPTION
1
P3V3
2
CPLD_LED3
3
GND
