Pinouts
C - 1
C - Pinouts
C.1 Parallel Information
Lantronix uses standard Centronics parallel connectors.
For optimum performance of your Server, Lantronix recommends the use of high quality
parallel cables. Choose one of the following:
¥ A Lantronix parallel port cable, part number #500-011 (6 feet).
¥ Any other brand of IEEE Std 1284-1994 compliant cable. Compliant
cables can easily be identiÞed by the permanent label ÒIEEE Std
1284-1994 compliantÓ on the cable itself.
NOTE: Non-compliant cables have the same type of connectors but different
electrical characteristics.
