HDK8450 (SM8450P) Processor User Guide Main board
80-28453-2 Rev. C Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 14
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
The PM8010 device is a dedicated camera PMIC that
integrates all the necessary power management,
housekeeping, and interface support functions into a
single IC.
▪ I2C/SPMI interface support for interrupt communication
(default slave I2C address is 0x08).
▪ Seven low-dropout linear (LDO) linear regulators
▪ Overtemperature protection
▪ I2C/SPMI with 400 kHz and 2.2 kΩ pull-up resistor
▪ Undervoltage lockout (UVLO) support
▪ High PSRR and low-noise regulators for camera
sensor applications
▪ 20-pin wafer-level picoscale package (WLPSP)
The PMR735A device is a power management IC that is
designed to power RF circuits. It integrates all the
necessary power management, housekeeping, and
interface support functions into a single IC.
▪ One HFS515 SMPS and two FTS520 SMPS
▪ Seven LDO linear regulators
▪ On-chip ADC
▪ Four GPIOs
▪ SPMI
▪ 48-pin wafer-level nanoscale package (WLNSP)
Wi-Fi 2.4
GHz/5GHz
via
WCN6856 –
PCIE,UART
Wi-Fi WCN6856
Wi-Fi + BT Combo
Chip
802.11a/b/g/n/ac/ax 2.4/5.0 GHz
BT 2.4 GHz
via
WCN6856 –
UART /
SLIMbus
Wi-Fi WCN6856
Wi-Fi + BT +FM
Combo Chip
Support BT 5.2 + HS and backward compatible with
BT 1.x, 2.x + EDR
4 x 4-Lane
MIPI CSI
DPHY or
4 x 3-Trio
MIPI CSI
CPHY
1 x 160-pin Camera
Connector for
CSI0, CSI1, CSI2
and CSI3
D-PHY v1.2 2.5 Gbps per lane
C-PHY v1.2 10.26 Gbps per T
1 x 4-Lane/1
x 2-Lane
MIPI CSI
DPHY or
4 x 3-Trio
MIPI CSI
CPHY
1 x 60-pin Camera
Connector for
CSI4, CSI5 on
expansion card
D-PHY v1.2 2.5 Gbps per lane
C-PHY v1.2 10.26 Gbps per T
2 x 60-pin
GenX
connector
Confidential -- Lantronix, Inc. Lantronix NDA Requir
ed
