Page #15 background imageLoading...
Page #15 background image
HDK8450 (SM8450P) Processor User Guide Main board
80-28453-2 Rev. C Confidential Qualcomm Technologies, Inc. and/or its affiliated companies May Contain Trade Secrets 15
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
Subsystem /
Connectors
Feature Set
Specification
1 x 30-pin
Vertigo
connector
I3C, I2C, SPI
1 x 60-pin
GenX
connector
I3C, I2C, SPI
1 x 24-pin
legacy
sensor
connector
I3C/I2C, SPI
Audio
Onboard
Audio Codec
WCD9385
Analog differential output
Digital output
Analog differential output
Digital input
Analog differential input
Digital input/output
Display
Expansion
2 x 4-Lane
MIPI DSI
DPHY or
2 x 3-Trio
MIPI DSI
CPHY
D-PHY1.2 2.5 Gbps per lane
C-PHY1.1 2.5 Gsymbols per trio
HDMI
Resolution
Up to 4K
60Hz via
LT9611UXC
Compliant with HDMI2.0
3.3 Dip switch configuration option
There are two DIP switches S5701 and S5702 on the bottom side of the HDK8450 Main board.
The 8-bit switch of S5701 allows the user to control the system configuration and boot option.
Table 3-3 Dip Switch S5701 Configuration
Function
DIP
Switch
Description
Notes
FORCED_USB_BOOT
S5701-1
Enable Emergency Download when
DIP switch turned on. Controlled by
GPIO47.
Default out of the box
configuration is OFF
FASTBOOT(0)
S5701-2
Enable other boot configuration when
DIP switch turned on. Controlled by
GPIO67.
Default out of the box
configuration is OFF.
tech.intrinsyc.com
Confidential -- Lantronix, Inc. Lantronix NDA Requir
ed
