HDK8450 (SM8450P) Processor User Guide Main board
80-28453-2 Rev. C Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 31
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
Pin#
Signal
Descriptio
n
Pin#
Signal
Description
J6001[17]
NC
J6001[18]
GND
J6001[19]
GND
Ground
J6001[20]
NC
J6001[21]
MIPI_DSI0_CLK_P_
DISP
DSI0 clock
J6001[22]
NC
J6001[23]
MIPI_DSI0_CLK_M_
DISP
DSI0 clock
J6001[24]
GND
J6001[25]
GND
Ground
J6001[26]
NC
J6001[27]
MIPI_DSI0_LANE0_
P_DISP
DSI0 data
J6001[28]
NC
J6001[29]
MIPI_DSI0_LANE0_
M_DISP
DSI0 data
J6001[30]
GND
J6001[31]
GND
Ground
J6001[32]
NC
J6001[33]
MIPI_DSI0_LANE1_
P_DISP
DSI0 data
J6001[34]
NC
J6001[35]
MIPI_DSI0_LANE1_
M_DISP
DSI0 data
J6001[36]
NC
J6001[37]
GND
Ground
J6001[38]
NC
J6001[39]
MIPI_DSI0_LANE2_
P_DISP
DSI0 data
J6001[40]
GND
J6001[41]
MIPI_DSI0_LANE2_
M_DISP
DSI0 data
J6001[42]
NC
J6001[43]
GND
Ground
J6001[44]
NC
J6001[45]
MIPI_DSI0_LANE3_
P_DISP
DSI0 data
J6001[46]
GND
J6001[47]
MIPI_DSI0_LANE3_
M_DISP
DSI0 data
J6001[48]
NC
J6001[49]
GND
Ground
J6001[50]
NC
J6001[51]
DSI0_NC_CLK1_P_
CON
J6001[52]
GND
J6001[53]
DSI0_NC_CLK1_M_
CON
J6001[54]
NC
J6001[55]
GND
Ground
J6001[56]
NC
J6001[57]
NC
J6001[58]
GND
J6001[59]
NC
J6001[60]
NC
