11.10 Sound Pitch
Press
again to set sound pitch.
Output pitch for all four warnings will begin to flash
Press or to change pitch.
”1” is very low pitch,”9” is very high pitch.
NOTE: When selecting a pitch on either side of 7 (3,800 Hz), the output volume will
decrease about 5 dB because the speaker is no longer at its optimum resonance frequency.
11.11 Test Warning Sounds
Press again to test warning sounds.
“Test” will begin to flash.
Press or .
This causes the PROTRACK II to sound the preset alarm sequence at the selected pitch
and volume. To stop the Test Warning Sounds, press , or .
