LTI TruPulse 360R User’s Manual Page 34
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Notes about Measurements

• Press
or to scroll through the individual measurement functions
and see the results acquired for each function.
o Azimuth, inclination, and distance are measured in the HD, SD, VD modes.
o Example Range Measurement: HD = 12.5 meters
VD = 1.6 meters
SD = 12.6 meters
INC = 7.3 degrees
AZ = 163.6 degrees
Note: Only International lasers include meters.
o When you scroll to the Height Function, the Main Display will be blank and
the HD indicator will be flashing.
o In the Inclination Mode, the Main Display is blank for all other measurement
functions (except AZ) since the laser is not active when measuring inclination
only.
o In Azimuth mode, the Main Display is blank for all other measurement
functions since the laser is not active when measuring azimuth only.
o In the Missing Line Mode, the "SHot_1" appears in the Main Display and the
HD indicator is flashing.
• The last measurement does not need to be cleared before acquiring your next target.
• Each time the TruPulse 360R is powered ON, it returns to the same measurement
mode that was last used.
• The measuring point of the TruPulse 360R is located at the center point of the
instrument, the ¼-20 thread.
Inclination Measurements
The laser is not active in the Inclination (INC) Measurement Mode. Generally, the inclination is
measured when you press
. However, in (1) the Continuous Target Mode and (2) in the Height
Measurement Mode, the inclination reading appears in the Main Display and the display updates as
your aiming point changes as long as you press
.
Percent Slope
Percent slope (indicated by “PERCENT”) is a calculation equal to 100 times the tangent of the
inclination angle. It is a variant way of expressing the inclination. You can get percent slopes only
in the basic measurement displays, never in the Height measurement displays. Note also that the
instrument never downloads a percent slope. It always downloads the inclination angle.

An inclination angle of 5 degrees, for example, is equal to a slope of about 8.75
percent.
