LTI TruPulse 360R User’s Manual Page 30
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Horizontal Angle Compass Calibration Menu
1. From the Measurement Mode, press
for 4 seconds to access the System Setup Mode. “UnitS”
will appear in the Main Display.
2. Press
to display the “H_Ang” option.
3. Press
to select the “H_Ang” option. The message “dECLn” appears in the Main Display.
4. Press
to display the "HACAL" option.
5. Press
to select the “HCAL” option. The message “no" "CAL” appears in the Main Display
and the display should look similar to Figure #18.
Figure #18
Press
or to display the previous or next "HACAL" option.
If "no" "dECLn" is displayed, press
to exit the "HACAL" menu and return to the Measurement
Mode.
If "YES" "CAL" is displayed, press
to begin the horizontal angle compass calibration routine.
The message "C1_Fd" appears in the Main Display.
To Next Page
