Mounting Unit on Wall
The supplied screws are intended
* Wall mounting template is located on
the back cover of this guide.
for use on a thick wooden wall
or wooden column. Do not use
them on any other materials.
There is a danger that the unit
may come off if used on the
other materials.
Install wall mount screws (supplied)
into a wall 10 cm (3-15/16") apart. Be
sure to keep about 3 mm (1/8") of the
screw head out of the wall. Use
template on the bottom of the back
side of this manual if you prefer.
10cm (3-15/16")
3mm
(1/8")
Mount the wall mount fittings
as shown on the right.
Plug the unit into power, and
the unit is ready to use.
The unit can be mounted on a wall using the supplied mounting fittings.
1
2
3
Wall
Wall Mount Template*
Screws
Make sure the power is off before mounting.
