LAUNCH TECH X-431 PRO - VCI Connector (Only Applies to 12 V Cars)

LAUNCH X-431 PRO (DBSCar V) User Manual
5
 Press it to activate the LCD if the LCD is off.
 Press it to turn off the LCD if the LCD lights up.
 Press it for 3 seconds to turn it off.
 Press it for 8 seconds to perform forced
shutdown.
3 LCD Screen
4 Rear Camera
5
USB/Charging
Port
 To connect to AC outlet for charging.
 To connect to PC for data exchange.
6 Speakers
7 Microphone
2.3 VCI Connector (Only applies to 12V cars)
The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle’s DLC (Data Link Connector) socket directly or via
OBD II extension cable to read the vehicle data and then send it to the X-431
PRO handset via Bluetooth.
