13 Packaging
Appendix：Transportation Guide
z The packaging of each model would include: 1# Angle iron bracket packaging and 2# cardboard box packaging. 3#
top beam packaging, 4# extension column packaging, Transportation guide is printed on packing.
z While using forklift to lift the 1# packaging, t
he fork arms must be of same distance from the center of the
packaging and the distance between two fork arms should at least be 700mm. While using a forklift to pick up
goods, the forks should get into the area below them as deep as possible. The goods should not be touched by
fork tips or pushed by them. Product damages caused by collision or high piling should be avoided
Model Name
1# Angle iron
bracket packaging
2# cardboard box
packaging
3# top beam
packaging
4# extension
column packaging
Size
Length ×Width
×Height
Size
Length ×Width
×Height
Size
Length ×Width
×Height
Size
Length ×Width
×Height
1 TLT235SB
3.5t
economical
floor-plate
two post lift
2900×540×660 850×230×300
2 TLT240SB
4.0t
economical
floor-plate
two post lift
2900×540×660 850×230×300
3 TLT235SC
3.5t
economical
clear-floor
two post lift
2900×600×650 850×230×300 2900×180×150 1180×230×390
4
TLT240SC
4.0t
economical
clear-floor
two post lift
2900×600×650 850×230×300 2900×180×150 1180×230×390
TLT240SC
(for
domestic)
4.0t
economical
clear-floor
two post lift
3920×600×650 850×230×300
5
TLT235SC
(U)
3.5t
economical
clear-floor
two post lift
3920×600×650 860×520×390 2900×180×150
