TLT235、TLT240 Economical Two-post User’s Manual
1
1. Outline
1.1 Model Description
Model Description
TLT235SC（U）clear-floor 2-post lift 3.5T Economical clear-floor 2-post lift (Fig.1a、Fig.2a、Fig.3a)
TLT235SC clear-floor 2-post lift
3.5T
Economical clear-floor 2-post lift (Fig.1b、Fig. 2b
1
、Fig. 3b
1
)
TLT240SC clear-floor 2-post lift
4.0T
Economical clear-floor 2-post lift (Fig.1b、Fig.2b、Fig.3b)
TLT235SB floor-plate 2-post lift
3.5T
Economical symmetric floor-plate 2-post lift (Fig.1c、Fig.2c)
TLT240SB floor-plate 2-post lift
4.0T
Economical symmetric floor-plate 2-post lift (Fig.1c、Fig.2c)
1.2 Purpose
This machine is applicable for the lifting of various small
and medium-sized vehicles with total weight below 3.5t/4.0t
in garage and workshop.
1.3 Functions and Features
z The cable and oil pipe are fully concealed, with
decent and elegant appearance.
z Designed based on the international standard,
meeting the demand of the garage and workshop.
z Top limit switch, effectively protecting the vehicle
from overhead collision.
z Dual hydraulic cylinders drive, stable lifting and
lowering.
z Manual lowering, safe and simple in operation.
z Adopt two steel cables for equalization, force two
carriages to move synchronously, and effectively
prevent the vehicle from tilting.
z Lowest height of lifting pad is 110mm, good for
repairing low chassis or low profile car.
1.4 Technical Specifications
Noise:
Working noise: ≤ 75dB（A）
Power unit:
Working pressure:
16MPa TLT235SC(U)
16MPa TLT235SC
16MPa TLT235SB
18 MPa TLT240SB
18 MPa TLT240SC
Electrical parameters of the machine：
Motor (optional)
Voltage：According to client’s requirement
Single phase: 110V/60Hz 2.2kW ； 220V/50Hz 2.2 kW
Single phase: 200V/60Hz 2.2 kW
Three phase 380V/50Hz 2.2 kW
