LAUNCH X-431 Euro Mini User Manual

•

Value

: Switches the current graph display mode to Value display mode.

•

Report

: To save the current data in text format. All reports are saved under

the tab “Diagnostic Report” in “My Report” from “User Info” menu.

•

Record

: Tap to start recording diagnostic data for future playback and

analysis. The file is stored in “My Report” under “User Info” menu.

Report

: To save the current data in text format. All reports are saved under the

tab “Diagnostic Report” in “My Report” from “User Info” menu. For details on

report operations, please refer to Chapter 9.1 “My Report”.

Record

: Tap to start recording diagnostic data for future playback and analysis.

The saved file follows the naming rule: It begins with vehicle type, and then the

record starting time and ends with .x431 (To differentiate between files, please

configure the accurate system time). The file is stored in “My Report” under

“User Info” menu.

Fig. 5-18

Help

: Tap to view the help information.

E. Actuation Test

This option is used to access vehicle-specific subsystem and component tests.

Available test vary by vehicle manufacturer, year, and model.

During the actuation test, the tool outputs commands to the ECU in order to

drive the actuators, and then determines the integrity of the system or parts by

reading the ECU data, or by monitoring the operation of the actuators, such as

switching a injector between two operating states.

www.diagtools.eu, Pernavas 43A, Riga, Latvia, LV-1009, +37129416069, info@diagtools.eu
